FS-12241
2U Rackmount chassis for Mini-ITX systems
2U Rackmount chassis for Mini-ITX systems
FS-12241 is a 2u rackmount chassis support dual Mini-ITX System. Featured 4 x 3.5" hotswappable HDD, interanal 2.5" or 3.5" HDD x 2 , and 2 x front accessible fan filter.Support 2 x low profile expansion cards.
**Motherboard and system components are not included, please contact our sales for system intergration inquiries**
Features
- 2U industrial rackmount for mini-itx motherboards
- Front accessible connectors: 2 x USB, 2 x CF slot, 4 x hot-swap trays
- Excellent cooling system with 4 x 80mm fans
| Product Specifications | |
| Model Number | FS-12241 |
| RoHS Compliance | Yes |
| Standard Drive Bays |
Internal Drive Bay : 2 x 2.5" and 4 x 3.5" Hot Swappable Drive Bay: 4 x 3.5" HDD Tray (Front) |
| Form Factor: | 2U |
| Motherboard Size: | Mini-ITX |
| Material | Heavy duty cold-rolled steel |
| Finish | Black wet paint textured coat |
| Color | Black |
| Weight | 30 |
| Mounting Option | Optional Sliding rails |
| Front LED Indicator | 2 x Activity; 2 x Power |
| Front USB Port | 2 |
| Front Power Switch | 2 |
| Memory Height | Accepts standard size |
| Expansion Slot | 2 x Low Profile |
| Compact Flash Slot | 2 |
| Cooling System: | 4 x 80mm fan |
| I/O Shield | Standard I/O (Not Included) |
| Supported PSU Type | Flex ATX |
| Dimensions (WxHxD) | 19.00" x 3.46" x 17.50" 482.6 mm x 87.9 mm x 444.5 mm |
