FS-12920
2U Rackmount chassis for ATX System
2U Rackmount chassis for ATX System
FS-11900 is another unique 2u chassis feature 2 x 3.5" hot swappable drive bays ,front IO and front AC socket for easy access. Support ATX motherboard and 4 x full height expansion slots.
**Motherboard and system components are not included, please contact our sales for system intergration inquiries**
Features
- 2U industrial rackmount chassis for Baby-ATX motherboard (9.6" x 12")
- Multi I/O in the front panel
- With 2 x 3.5" hot swap tray
- Excellent cooling with 2 x 8cm fan
| Product Specifications | |
| Model Number | FS-12920 |
| RoHS Compliance | Yes |
| Standard Drive Bays |
Internal Drive Bay : 2.5" HDD x 1 + 3.5" HDD x 2 Hot Swappable Drive Bay: 2 x 3.5"HDD |
| Form Factor: | 2U |
| Motherboard Size: | ATX |
| Material | Heavy duty cold-rolled steel |
| Finish | Black wet paint with texture coat |
| Color | Black. Customizable colour |
| Front LED Indicator | 2 x disk activity (Orange light) ; 2 x power on (Blue light) |
| Front USB Port | 2 |
| Memory Height | Accept standard size |
| Expansion Slot | 4 |
| Cooling System: | 8cm fan x 2 |
| I/O Shield | 1 (not included) |
| DB9 Cutoff Hole | 2 |
| Supported PSU Type | Flex ATX |
| Dimensions (WxHxD) | 19.00" x 3.46" x 15.24" 482.6 mm x 87.9 mm x 387.1 mm |
