FS-12421
2U Rackmount chassis for ATX System
2U Rackmount chassis for ATX System
FS-12421 is a 2u rackmount chassis support ATX motherboard. Support 2 x 2.5" hotswappable HDD, 1 x internal 2.5" HDD, 4 x full height expansion cards and FLEX ATX power supply.
**Motherboard and system components are not included, please contact our sales for system intergration inquiries**
Features
- 2U industrial rackmount chassis for Baby-ATX motherboard (9.6" x 12")
- Support 4 x full size expansion slot
- With 2 x 2.5" hot swap tray
- Excellent cooling with 2 x 6cm fan and 2 x 4cm fan
| Product Specifications | |
| Model Number | FS-12421 |
| RoHS Compliance | Yes |
| Standard Drive Bays |
Internal Drive Bay : 1 x 2.5"HDD Hot Swappable Drive Bay: 2 x 2.5"HDD |
| Form Factor: | 2U |
| Motherboard Size: | ATX (9.6" x 12") |
| Material | Heavy duty cold-rolled steel |
| Finish | Black wet paint with texture coat |
| Color | Black. Customizable colour |
| Front LED Indicator | 2 x disk activity (Orange light) ; 2 x power on (Blue light) |
| Front USB Port | 2 (USB 2.0) |
| Front Audio In/Out | none |
| Memory Height | Accept standard size |
| Expansion Slot | 4 |
| Compact Flash Slot | none |
| Cooling System: | 4cm fan x 2 + 6cm fan x 2 |
| I/O Shield | 1 (not included) |
| Supported PSU Type | Flex ATX |
| Dimensions (WxHxD) | 19.00" x 3.46" x 10.42" 482.6 mm x 87.9 mm x 264.7 mm |
