Industrial Chassis | iStarUSA Products | BPU-228DE-SS - Build-to-Order - 2x 5.25" to 8x 2.5" SATA SAS 6 Gbps HDD SSD Hot-swap Rack

BPU-228DE-SS
Build-to-Order - 2x 5.25" to 8x 2.5" SATA SAS 6 Gbps HDD SSD Hot-swap Rack

High Performance Transfer Rate Up to 6.0 Gb/s
All Aluminum Material Solid Construction
Plug & Play, Hot Swappable
Built-in 70mm Cooling Fan
LEDs for Power & HDD Activity
Supports 8x 2.5" SAS I/II (Primary Channel) and SATA I/II/III HDDs/SSDs
Support HDD Thickness up to 14.5 mm

Product Introduction
High availability storage in compact design, BPU-228DE-SS adds extra storage and hot-swap capability to satisfy any application needs. The BPU-228DE-SS is constructed of aluminum material that provides best heat dissipation required for high performance 2.5" SATA and SAS drives. The housing is designed with excellent front to back airflow cooling with a 70mm fan. BPU-228DE-SS is an ideal solution for 2.5" HDD SSD RAID and JBOD applications.

Specifications	Download	FAQ
Optional Accessories	Compatible Power Supplies	Compatible Motherboards
	Product Reviews

Model Number	BPU-228DE-SS
RoHS Compliance	Yes
Standard Drive Bays	Hotswap 2.5": 8 5.25" Drives: 2
Hotswap HDD Type:	2.5" SAS I/II & SATA I/II/III
Indicators	Blue:power on. Fast Red Blinking:overheating. Slow Red Blinking:fan failure
Security	Key Lock
Material of Main Chassis	Aluminum
Color of Main Chassis	Black
Cooling Fan	1x70mm
Dimensions (WxHxD)	5.75" x 3.35" x 6.30" 146.0 mm x 85.1 mm x 160.0 mm
Notes	- HTS code: 8573.30.5100. ECCN: EAR99
